Description

DESCRIPTION:
Excellent,Precision,Industrial  Multi-Process Welders

Dual welding process: TIG DC / MMA (Stick).
Arc stability and control.
With HF arc starting.
Possibility of choosing between welding cycle 2T or 4T.
Post-gas time adjustable.

Digital instrument for the welding current.
Auto-Protection against over-voltage,over-current and over-heated.
Smaller, lighter and portable, this equipment is protected by a solid metal casing.

Parameters Specification
Rated Input Voltage(V) AC415V±15% 1P
Arc-Initiating(TIG) H-F
Rated Input Current(A) TIG:41 MMA:58
Efficiency(%) 85
Input Frequency (HZ) 50/60
Power Factor 0.73
Rated Input Power(KVA) TIG:8.4 MMA:12
Protection Grade IP21
Open Circuit Voltage(V) 56
Weight(kg) 19
Current Range(A) 10-300
Dimension(mm) 505*203*375
Duty cycle at maximum current 60%@25

Standard Accessories:
Water cool tig torch
Earth clamp with cable

6 MONTH CIRCUIT WARRENTY
